Belly Nevada 16710-33

Ordering Information

Part Number: 16710-33

Description: Armored interconnect ribbon-cable assembly for 3500 Series racks

Series: 3500 Interconnect Cables

Length: 0.30 m nominal (custom lengths available upon request)

Connector A: 50-pin ribbon-cable header (mates to card P2 backplane)

Connector B: 50-pin high-density D-sub male, metal shell

Armor: Stainless-steel conduit over PVC jacket (provides mechanical protection)

Accessory: Integrated strain-relief clamps on both ends

Technical Parameters

Conductors: 28 AWG tinned-copper, flat ribbon cable (50 conductors)

Impedance: ~ 60 Ω differential pair sections

Voltage Rating: 125 V DC max

Current Rating: 1 A per conductor (suitable for low-power logic signals)

Insulation Resistance: ≥ 100 MΩ at 500 V DC

Armor Material: 304 stainless steel flexible conduit over PVC jacket

Operating Temperature: –20 °C to +70 °C for Bently Nevada 16710-33

Certifications: RoHS-compliant; UL recognized component

Product function

Routes digital and analog I/O signals through Bently Nevada 16710-33 from 3500 Series modules through an armored harness to external termination points. Maintains precise conductor spacing to preserve signal timing, supports hot-swap module replacement, and consolidates 50 conductors in a single robust assembly.

Application Areas

Industrial Control Cabinets: Internally connecting rack modules using Bently Nevada 16710-33 to bulkhead terminations in power plants.

Marine & Offshore Platforms:Withstanding salt-spray and vibration with Bently Nevada 16710-33 in shipboard enclosures.

Petrochemical & Chemical Plants: Resisting chemical splash via Bently Nevada 16710-33 in hazardous-area panels.

OEM Machinery Skids: Embedded in skids requiring durable interconnects like Bently Nevada 16710-33.

Test & Calibration Benches: Providing protected harnesses for systems incorporating Bently Nevada 16710-33 without cable fatigue.
